EM400-MUD-868M-B045-2 - Multifunctional Ultrasonic Distance Sensor

EM400-MUD is a multifunctional ultrasonic distance sensor designed to detect small-range areas and small blind spots. It features switchable pre-set modes for different applications. EM400-MUD is also equipped with a 3-axis accelerometer and temperature sensor to detect device status. With high protection IP rating and waterproof enclosure, EM400-MUD can withstand harsh environments and operate up to 10 years using two 9000 mAh batteries.

The LoRaWAN®version can be integrated with a Milesight LoRaWAN® gateway, enabling remote and visual management of all sensor data.

Features

• 3-450 cm wide detection range with small blind zone
• Equipped with NTC temperature sensor for the detection and alarm of trash burning
• Built-in 3-axis accelerometer sensor to monitor device tilt status
• Damp-proof coating inside and IP67 waterproof enclosure for outdoor applications
• Two built-in 9000 mAh replaceable batteries that work for up to 10 years without replacement
• Equipped with NFC for one touch configuration, support card emulation mode

• Equipped with three pre-set modes for different applications: standard mode, bin mode, packing lot mode
• Ultra-wide-distance wireless transmission up to line of sight of 15 km
• Function well with standard LoRaWAN® gateways and network servers

Measuring Range

• Detection Range: 3 ~ 450 cm
• Resolution: 1 mm
• Status: Normal / Tilt
• Flame Retardant Grade: V0
